Keyless & Batteryless
Access Control Solutions
NFC Cylinders
The Phoenix Smartlocks keyless, battery-free NFC digital cylinder lock operates entirely without physical keys, requiring only an Android or iOS smartphone for access. It wirelessly harvests energy from the user’s smartphone, making it a truly battery-free, maintenance-free solution.
ELECTRONIC / CYBERSECURITY FEATURES
- NFC communication compliant with ISO 14443A
- Unique, non-duplicable electronic identity
- Unique access codes per lock
- Programmable access permissions (time-limited and access-count based)
- AES-256 encrypted communications
- Protection against external interference and replay attacks
- Internal memory for up to 1,000 access events
- Programmable time-based auto-deactivate feature (0-10 seconds)
- Compatible with Android and iOS devices
MECHANICAL & PHYSICAL DATA
- Brass body with chrome-plated finish
- Free rotating knob, made of high strength Polyoxymethylene (POM)
- Highly modular design enabling multiple lock length configurations, from 30mm up to 100mm in 5mm steps
NFC European Profile
Modular Cylinder
SEC-30/10
SEC-30/10 is a keyless and batteryless NFC digital cylinder lock from Phoenix Smartlocks. Its operation is entirely key-free, requiring only an Android or iOS smartphone to unlock it. SEC-30/10 harvests energy wirelessly from the user’s smartphone, making it a truly battery-free and maintenance-free device.
It features a modular design that accommodates lengths of up to 100mm.
Compatible with Android and iOS phones.
OPERATIONAL FEATURES
SEC-30/10 can be setup to work in two operational modes, which can be configured in the smartphone App.
- Manual mode: Both opening (activating the knob) and closing (deactivating the knob) procedures require using the smartphone to interact with the lock.
- Auto-deactivate mode: Opening the lock requires using the smartphone to interact with the lock. In this mode there is no need to manually deactivate the lock, since after a successful open operation, the lock will auto-deactivate after a pre-set (and configurable in the app) amount of time.
ENVIRONMENTAL SPECIFICATIONS
- Operating temperature range: -40°C to +80°C
- Ingress protection: IP55
